MERGED QUESTION Question from salimmasumdar: 'LVDS to DVI using LVDS interface signals' The processor has a module for providing a low voltage differential signaling (LVDS) output interface. This module converts the RGB signals output from video display controller 5 to the LVDS format that has six bits each for R, G, and B signals, and outputs the converted signals. It has a dedicated phase-locked loop (PLL) circuit, which can generate a clock with a desired frequency by dividing or multiplying the input clock frequency. The clock output from this PLL can be used as the panel clock for video display controller 5 even when LVDS output is not used.

This PLL is called LVDS PLL in this section. • Four pairs of differential output conforming to the TIA/EIA-644 standard (three pairs for data and one pair for the clock) TXOUT0P TXOUT0M TXOUT1P TXOUT1M TXCLKOUTP TXCLKOUTM TXOUT2P TXOUT2M how can i use these signals to output to DVI.

Digital signage software linux open source mac. The computer will be connected to network, but will have no input devices, and thus shouldn't have a graphical desktop environment.

I am trying to get the output on a screen that support DVI connection. But the chip gives the output for LVDS connector. Here i am tring to uses these signals to get an output on my screen that supports DVI since this is 18-bits RGB i dont understand how it will work for a 24bit DVI.
