Full Bridge Mosfet Driver

Product Details The LT1160/LT1162 are cost effective half-/full-bridge N-channel power MOSFET drivers. The floating driver can drive the topside N-channel power MOSFETs operating off a high voltage (HV) rail of up to 60V. The internal logic prevents the inputs from turning on the power MOSFETs in a half-bridge at the same time. Its unique adaptive protection against shoot-through currents eliminates all matching requirements for the two MOSFETs. This greatly eases the design of high efficiency motor control and switching regulator systems. During low supply or start-up conditions, the undervoltage lockout actively pulls the driver outputs low to prevent the power MOSFETs from being partially turned on. The 0.5V hysteresis allows reliable operation even with slowly varying supplies.

The MAX5062/MAX5063/MAX5064 high-frequency, 125V half-bridge, n-channel MOSFET drivers drive high-and low-side MOSFETs in high-voltage applications. These drivers are independently controlled and their 35ns typical propagation delay, from input to output, are matched to within 3ns (typ).

The LT1162 is a dual version of the LT1160 and is available in a 24-pin PDIP or in a 24-pin SO Wide package. Applications • PWM of High Current Inductive Loads • Half-Bridge and Full-Bridge Motor Control • Synchronous Step-Down Switching Regulators • 3-Phase Brushless Motor Drive • High Current Transducer Drivers • Class D Power Amplifiers.

LTspice LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits. To launch ready-to-run LTspice demonstration circuits for this part: Step 1: Download and install LTspice on your computer. R4 sdhc nintendo ds. Step 2: Click on the link in the section below to download a demonstration circuit. Step 3: If LTspice does not automatically open after clicking the link below, you can instead run the simulation by right clicking on the link and selecting “Save Target As.” After saving the file to your computer, start LTspice and open the demonstration circuit by selecting ‘Open’ from the ‘File’ menu. Status Status indicates the current lifecycle of the product. This can be one of 4 stages: • Pre-Release: The model has not been released to general production, but samples may be available. • Production: The model is currently being produced, and generally available for purchase and sampling.

• Last Time Buy: The model has been scheduled for obsolescence, but may still be purchased for a limited time. • Obsolete: The specific part is obsolete and no longer available. Other models listed in the table may still be available (if they have a status that is not obsolete). Production Availability This is the date Analog Devices, Inc.

Anticipates that the product will ship from the warehouse. Most orders ship within 48 hours of this date.Once an order has been placed, Analog Devices, Inc. Will send an Order Acknowledgement email to confirm your delivery date. It is important to note the scheduled dock date on the order entry screen. We do take orders for items that are not in stock, so delivery may be scheduled at a future date.

Also, please note the warehouse location for the product ordered. We have warehouses in the United States, Europe and Southeast Asia. Transit times from these sites may vary. Sample availability may be better than production availability. Please enter samples into your cart to check sample availability.
